20 meters 50-7 (RG8/U) coaxial cable with L16 NJ+NJ connector

  • Model: 50-7-N-20
  • Shipping Weight: 3 Kg
  • 10 Units in Stock

(image for) Ask a Question

USD $45.00

Add to Cart:

FEATURE

  • Cable type: 50-7 (RG8/U) coaxial cable.
  • L16 NJ+NJ male connectors on each cable end.
  • Length: 20 meters.

Electrical performance

project standard remark
Impedance 50 ohm
Jacket Color Black
Jacket Material Non-halogenated, fire retardant polyolefin
Braid Material Tinned copper
Shield Tape Material Aluminum
Dielectric Material Foam PE
Inner Conductor Material Copper-plated aluminum

Attenuation factor and rated average power

Frequency Attenuation (dB/100 m) Attenuabon (dB/100 ft)
30 MHZ 2.49 0.76
50 MHz 3.18 0.97
150 MHZ 4.92 1.5
220 MHz 6.23 1.9
450 MHz 8.86 2.7
900 MHz 12.8 3.9
1500 MHZ 16.7 5.1
1800 MHZ 18.4 5.6
2000 MHz 19.4 5.9
2400 MHZ 21.65 6.6
2500 MHZ 22 6.7
3000 MHZ 24.6 7.5
4000 MH 28.87 8.8
4500 MH 30.84 9.4
5000 MHz 32.81 10
5200 MHZ 33.46 10.2
5500 MHZ 34.78 10.6
5800 MHZ 35.76 10.9
6000 MHz 36.42 11.1
